INSIZE 3661-80 高精度大行程直进式数显千分尺 (50-80mm; ±3μm )

Features:

Carbide measuring faces

Data output

Button fuction: mm/inch, max./min. value tracking, preset value, hold, on/off, zero

CR2032 battery

Automatic power off, turn the sleeve to turn on

Specifications:

Resolution: 0.01mm/0.0005", 0.001mm/0.00005", 0.0005mm/0.00002"

Repeatability: 0.5μm

Measuring force: 5-10N

Flatness of measuring faces: 0.3μm;

Parallelism of measuring faces: 0.5μm

Optinal accessary: setting standards (code 7386), data output cable (code 7305-A03, 7305-SPC4, 7306-80)

Range: 50-80mm/1.97-3.15"

Accuracy: ±3μm

Length: 88mm


Detail

Ratchet stop

Non-rotating spindle, suitable for cylinders

Quick measurement: one turn of sleeve or ratchet stop makes 2mm spindle feed

Datasheet
