INSIZE 5101-M500BD 工业显微镜 (50X~500X; 明场暗场物镜)

Illumination: 12V/50W halogen lamp, brightness is adjustable

Objective (infinite plan achromatic): bright and dark field objectives: 5X; 10X; 20X; 50X

Working distance: 9.70mm; 9.30mm; 7.23mm; 2.50mm

Numerical aperture: 0.12; 0.25; 0.40; 0.70

Magnification: 50X~500X

Eyepiece (wide field): 10X (view field: ϕ22mm)

Stage:

- Double layer

- Size: 160x140mm

- Travel: 35x30mm

Pupil distance: 53~75mm

Diopter adjustment: ±5 diopter (one eyepiece)

Power supply: 220V, 50/60Hz

Dimension: 415x345x380mm

Weight: 14kg

Standard delivery:

- Main unit: 1pc

- Anti- dust cover: 1pc

Optional accessory:

- Bright & dark field objective

- 10X dividing eyepiece (0.1mm/div.): 5101-M-EPD10X
