INSIZE 5307-ID100A Digital Measuring Microscope (12~77X)

Sensor: 1/2" CMOS

Pixel: 2M

Resolution: 1920x1080

Magnification: 12~77X

Objective magnification: 0.7X~4.5X

Measuring accuracy: ±5~±9mm

Focus distance: 100mm

View field: 2.7x1.9~17.5x11.9mm

Max workpiece height: 60mm

Frame rate: 60fps

Output: USB/HDMI

Power supply: power adapter

Dimension (LxWxH): 610x610x660mm

Weight: 4.5kg

Standard delivery:

- Main unit: 1pc

- Calibration plate: 1pc

- Power adapter: 1pc

- Mouse: 1pc

- 16G USB flash disk: 1pc
