INSIZE 6582-902 X轴位移平台 (± 12.5mm; 0.01mm)

Features:

Cross roller guides, achieve high precision and smooth movement

Stages made of aluminum alloy

Micrometer location: middle

Specifications:

X-axis displacement: ±12.5mm

Parallelism of top surface to bottom: 0.03mm

Micrometer graduation: 0.01mm

Micrometer accuracy: 0.02mm

Maximum load: 93.1N (9.5kgf)

Stage size: 90x90mm

Weight: 0.47kg
