INSIZE ISM-ZS200 平行光立体显微镜 (10X; 0.8X~8X)

Optical tube: binocular (20° inclined)

Eyepiece (wide field): 10X (view field: ϕ22mm)

Objective: 0.8X~8X (zoom)

Zoom ratio: 1:10

Pupil distance: 55~75mm

Diopter adjustment: ±5 diopter (both eyepiece)

Working distance of objective: 78mm

Max. workpiece height: 72mm

Illumination: adjustable reflected and transmitted LED light

Power supply: 110/220V, 50/60Hz

Dimension: 240x280x440mm

Weight: 4.3kg

Standard delivery:

- Main unit: 1pc

- WF 10X eyepiece: 2pcs

- Φ100mm glass plate: 1pc

- Φ100mm white/black plate: 1pc

- Anti-dust cover: 1pc

Optional accessory:

- Objective: 0.5X achromatic objective; 2X plan achromatic objective; 0.5X plan apochromatic objective

- Eyepiece: WF15X; WF20X; WF30X

- Sleeve for objective

- Iris diaphragm

- Optical path splitter

- Coaxial illumination

- Digital camera
