INSIZE ISR-C100 粗糙度仪 (160µm)

16 roughness parameters

With probe position indicator

Connected with printer via bluetooth

Can display roughness values, profile and curve

Memory of maximum 100 results

Automatic power off

Parameters:  Ra, Rq, Rv, Rp, Rm, Rt, RS,  Rsm, R3z, R3y, Rz, Rku, Rsk, Rmax, Rpc

Range: 160µm

Accuracy: ±3%

Resolution (Ra): 0.001µm

Probe type: inductive

Probe Stylus radius/ angle: 5µm/90 °

Probe stylus material: diamond

Measuring force: 4mN

Measuring unit: µm/µin

Cut off: 0.25/0.8/2.5mm

Numbers of cut-offs: 1-5

Traverse speed: 0.5mm/s, 1mm/s

Memory: 100 measurement results

Output: USB and bluetooth

Power: built-in rechargeable results

Dimension(L×W×H): 140x52x48m

Weight: 440g
