INSIZE LDM-065 激光扫描千分尺 (0.5~65mm;0.4 μm)

Measure outer diameter, ellipticity, run-out, maximum diameter of tools, ect.

Measuring range: 0.5~65mm

Resolution: 0.01/0.1/1/10/100 μm selectable

25°C accuracy: ±(0.5+5%D) μm; D is measuring diameter in mm

Repeatability: 0.4 μm

Laser wave length: 650mm

Measuring speed: 800~3200 times/s (adjustable)

Working temperature: 0~50°C

Working humidity: 35~85RH without condensation

Output: dual channel RS 485

Alarm output: 24V, 1A

Power supply: DC24V, 2A

Dimension: 469x52x156mm

Weight: 8kg

Standard delivery:

- Main unit: 1pc

- V-block: 1pc

- AC/DC adapter: 1pc

- RS485 cable: 1pc

Optional accessory:

- Calibration gage: custom made
